FOR SALE IS A PAIR OF
VUE Audiotechnik hs-20 Dual 10-Inch Compact High Output ACM Subwoofer
FREIGHT DELIVERY FOR RESIDENTIAL & LIMITED ACCESS AREAS
Residential Delivery Fee $95.00, Lift Gate Fee $95.00
Limited Access (Hospitals, Schools, Construction Sites,
Churches, Government Facilities
Gate Access, Storage Units, Remote Access, Etc.) $95.00
THIS IS IN ADDITION TO THE SHIPPING FEE
CONDITION
These subs may have minor scratches and
cosmetic blemishes from normal use.
These speakers are in good working
order and good condition. These subs have not been
opened or disassembled.
Sorry, no other parts, wiring or
accessories are included in this sale
SPECS
DESCRIPTION Active dual 10 inch ACM™ Subwoofer system
ACOUSTIC DATA
Frequency Response (+- 3 dB) 45 Hz – 70, 80, 90, 100,
or 120 Hz (Preset dependent)
Efficiency (1W/1m) 94 dB SPL
Max Peak SPL(band limited pink noise 6dB crest factor)
135 dB SPL half space129 dB SPL Free Field
Max SPL Long Term (SPL @ 1 M before protection Sine Wave) 123 dB SPL Free Field
Coverage Horizontal & Vertical 360 degrees – 6 dB
AMPLIFIER DATA
Amplifier Power (Long Term Sine Wave before protection)
LF 1: 500 wattsLF 2: 500 watts
Peak Amplifier Power ( @ 1% THD+N)
LF 1: 800 wattsLF 2: 800 watts
Amplifier Protection Input limiter, short circuit protection,
DC protection of output, intelligent mains fuse protection,
power stage overload protection, temperature
protection of transformers and heat-sinks
Operational Voltage Universal Mains, 85-268V
(dual voltage auto selection). UREC™ power supply
provides true universal worldwide mains operation for 120V and 230V
THD+N (typical) < 0,05 % (20 Hz – 20 kHz, 3 dB below rated power)
DSP 96k Hz sample rate, mixed-mode 64-bit digital
processing, 120 dB dynamic range,
less than 600 microseconds latency
Control Network Ethernet / TCP/IP, Fixed IP
or DHCP remote monitoring and control
TRANSDUCER DATA
LF Description Dual 10” paper cone, cloth surrounded,
woofers with dual layer, inside/outside 64 mm voice coils.. 4 ohm
PHYSICAL DATA
Inputs Female XLR input with male XLR loop output for both
Analogue input and AES EBU digital input (default digital AES
channel 1, channel 2 selectable remotely via software).
If clock is present system uses AES digital input.
System will fall back on analog input if clock is not present.
Dante network streams audio over ethernet.
Cabinet Material Multi-ply birch hardwood
Cabinet Surface Black 6-layer coating
Dimensions (H x W x D) 14.25 x 24.25 x 22 in (362 x 600 x 560 mm)
Weight Net: 78.9 lbs
